IP244
C79000–B8576–C866–01
7–19
The following table lists the technical specifications of the FC 162:
FC 162
Block number 162
Block name PER_TREG
Version 1.0
Assignments in the data area DB-A:
DBB 0 ... DBB 511
DB-B:
DBB 0 ... DBB 407
DB-C:
DBB 0 ... DBB 447
DB-A’:
DBB 0 ... DBB 447
DB-C’:
DBB 0 ... DBB 447
Assignments in the local data
area
26 bytes
Assignments in the flag area Flags are not used
Invoked system functions SFC 24 TEST_DB
SFC 47 WAIT
SFC 49 LGC_GADR
The following table lists the executon time values of the FC 162. They are
valid for the CPU 416-1.
FC 162
PA first invocation
second invocation
8 ms
4 ms
AE first invocation
second invocation
4 ms
4 ms
S1/S2, T1/T2, G1/G2 4 ms
AS, AB, HB, SE 4 ms
LE 4 ms
IW 4 ms
Read with error no additional time
Idling 4 ms
Specifications
Execution time
FC162
