Upgrading Existing Series 500 Installations

D-7

TI545/TI555 System Manual

P/S

TI555

Series

505 I/O

4, 8, or 16 slots

Local I/O

Upgrade Path

P/S TI560

TI565

12 3

TI545

Figur

e D-2

Upgrading

an RS-485 Based TI560/TI565/TI560T/TI565P System
