Installing and connecting the device
3.5 Connecting the device
IFP V2, IFP V2 PRO, IFP V2 ETH
Operating Instructions, 03/2023, A5E46641410-AE
59
Wiring diagram
The following figure shows the connection of the functional ground for the equipotential
bonding using IFP1500 V2 as an example and similarly applies to all Flat Panels and the
Transceiver Unit.
Cable routing for PRO devices
As the PRO device is not installed in a control cabinet but on a pedestal or support arm, the
connecting cables must be routed through the support arm or the pedestal. The cabl
e cross-
sections specified for the built
-in devices also apply to the PRO devices.
Observe the corresponding connection diagrams in the Quick Install Guide supplied with your
PRO device.
