1 NC/Drive Machine Data 08.96
1.4 Spindle-specific values (max. 6 spindles)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
417* - // - gear stage
7
2000 99999 -- rev/min
1)
418* - // - gear stage
8
2000 99999 -- rev/min
1)
419* Acceleration time constant
for gear stage 1
800 50000 -- 1 ms
420* - // - gear stage 2 800 50000 -- 1 ms
421* - // - gear stage 3 800 50000 -- 1 ms
422* - // - gear stage 4 800 50000 -- 1 ms
423* - // - gear stage 5 800 50000 -- 1 ms
424* - // - gear stage 6 800 50000 -- 1 ms
425* - // - gear stage 7 800 50000 -- 1 ms
426* - // - gear stage 8 800 50000 -- 1 ms
427* Creep speed M19,
gear stage 1
100 1500
16 000
4)
-- rev/min
1)
428* - // - gear stage 2 100 1500
16 000
4)
-- rev/min
1)
429* - // - gear stage 3 100 1500
16 000
4)
-- rev/min
1)
430* - // - gear stage 4 100 1500
16 000
4)
rev/min
1)
431* - // - gear stage 5 100 1500
16 000
4)
-- rev/min
1)
432* - // - gear stage 6 100 1500
16 000
4)
-- rev/min
1)
433* - // - gear stage 7 100 1500
16 000
4)
-- rev/min
1)
434* - // - gear stage 8 100 1500
16 000
4)
-- rev/min
1)
_____
1) If MD 520* bit 3=1, input resolution is 0.1 rev/min
2) Up to SW 2
3) SW 3 and higher
4) SW 4 and higher
1–14 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
