01.99 1 NC/Drive Machine Data
1.9.2 Axis-specific MD2
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
1708* Time const. paral. model 2nd para. set 6 000 16 000 -- 0.01 ms
1712* Time const. paral. model 3rd para. set 6 000 16 000 -- 0.01 ms
1716* Time const. paral. model 4th para. set 6 000 16 000 -- 0.01 ms
1720* Time const. paral. model 5th para. set 6 000 16 000 -- 0.01 ms
1724* Time const. paral. model 6th para. set 6 000 16 000 -- 0.01 ms
1728* Time const. paral. model 7th para. set 6 000 16 000 -- 0.01 ms
1732* Time const. paral. model 8th para. set 6 000 16 000 -- 0.01 ms
1736* Alarm limit velocity
1st para. set
1)
11 000 9999 9999 IS 1000 units/min
1740* Alarm limit velocity
2nd para. set
1)
11 000 9999 9999 IS 1000 units/min
1744* Alarm limit velocity
3rd para. set
1)
11 000 9999 9999 IS 1000 units/min
1748* Alarm limit velocity
4th para. set
1)
11 000 9999 9999 IS 1000 units/min
1752* Alarm limit velocity
5th para. set
1)
11 000 9999 9999 IS 1000 units/min
1756* Alarm limit velocity
6th para. set
1)
11 000 9999 9999 IS 1000 units/min
1760* Alarm limit velocity
7th para. set
1)
11 000 9999 9999 IS 1000 units/min
1764* Alarm limit velocity
8th para. set
1)
11 000 9999 9999 IS 1000 units/min
1768* Alarm limit acceleration
1st para. set
1)
55 16 000 IS units/s
2
1772* Alarm limit acceleration
2nd para. set
1)
55 16 000 IS units/s
2
1776* Alarm limit acceleration
3rd para. set
1)
55 16 000 IS units/s
2
1780* Alarm limit acceleration
4th para. set
1)
55 16 000 IS units/s
2
1784* Alarm limit acceleration
5th para. set
1)
55 16 000 IS units/s
2
1788* Alarm limit acceleration
6th para. set
1)
55 16 000 IS units/s
2
1792* Alarm limit acceleration
7th para. set
1)
55 16 000 IS units/s
2
1796* Alarm limit acceleration
8th para. set
1)
55 16 000 IS units/s
2
_______
1) SW 4 and higher
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–41
SINUMERIK 840C (IA)
