1 NC/Drive Machine Data 09.95
1.9.2 Axis-specific MD2
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
1596* Zero speed control 2nd para. set
1)
100 16 000
2)
MS units
1600* Zero speed control 3rd para. set
1)
100 16 000
2)
MS units
1604* Zero speed control 4th para. set
1)
100 16 000
2)
MS units
1608* Zero speed control 5th para. set
1)
100 16 000
2)
MS units
1612* Zero speed control 6th para. set
1)
100 16 000
2)
MS units
1616* Zero speed control 7th para. set
1)
100 16 000
2)
MS units
1620* Zero speed control 8th para. set
1)
100 16 000
2)
MS units
1624* P comp. compensat. contr. 2nd para. set 0 16 000 -- 1
1628* P comp. compensat. contr. 3rd para. set 0 16 000 -- 1
1632* P comp. compensat. contr. 4th para. set 0 16 000 -- 1
1636* P comp. compensat. contr. 5th para. set 0 16 000 -- 1
1640* P comp. compensat. contr. 6th para. set 0 16 000 -- 1
1644* P comp. compensat. contr. 7th para. set 0 16 000 -- 1
1648* P comp. compensat. contr. 8th para. set 0 16 000 -- 1
1652* I comp. compensat. contr. 2nd para. set
1)
0 16 000 -- 1
1656* I comp. compensat. contr. 3rd para set
1)
0 16 000 -- 1
1660* I comp. compensat. contr. 4th para. set
1)
0 16 000 -- 1
1664* I comp. compensat. contr.5th para. set
1)
0 16 000 -- 1
1668* I comp. compensat. contr. 6th para. set
1)
0 16 000 -- 1
1672* I comp. compensat. contr. 7th para. set
1)
0 16 000 -- 1
1676* I comp. compensat. contr. 8th para. set
1)
0 16 000 -- 1
1680* D comp. compensat. contr. 2nd para. set
1)
0 16 000 -- 1
1684* D comp. compensat. contr. 3rd para. set
1)
0 16 000 -- 1
1688* D comp. compensat. contr. 4th para. set
1)
0 16 000 -- 1
1692* D comp. compensat. contr. 5th para. set
1)
0 16 000 -- 1
1696* D comp. compensat. contr. 6th para. set
1)
0 16 000 -- 1
1700* D comp. compensat. contr. 7th para. set
1)
0 16 000 -- 1
1704* D comp. compensat. contr. 8th para. set
1)
0 16 000 -- 1
_______
1) SW 4 and higher
2) SW 4.4 and higher: 99 999 999
1–40 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
