09.95 1 NC/Drive Machine Data
1.9.2 Axis-specific MD2
D e s i g n a t i o n
MD
No.
Standard
value
Maximum
input value
Reference
system
Input
unit
1460* Time const., symm. filter 3rd para. set
1)
0 1 000 -- 0.1 ms
1464* Time const., symm. filter 4th para. set
1)
0 1 000 -- 0.1 ms
1468* Time const., symm. filter 5th para. set
1)
0 1 000 -- 0.1 ms
1472* Time const., symm. filter 6th para. set
1)
0 1 000 -- 0.1 ms
1476* Time const., symm. filter 7th para. set
1)
0 1 000 -- 0.1 ms
1480* Time const., symm. filter 8th para. set
1)
0 1 000 -- 0.1 ms
1484* Time const., setpo. filter 2nd para. set
1)
0 1 000 -- 0.1 ms
1488* Time const., setpo. filter 3rd para. set
1)
0 1 000 -- 0.1 ms
1492* Time const., setpo. filter 4th para. set
1)
0 1 000 -- 0.1 ms
1496* Time const., setpo. filter 5th para. set
1)
0 1 000 -- 0.1 ms
1500* Time const., setpo. filter 6th para. set
1)
0 1 000 -- 0.1 ms
1504* Time const., setpo. filter 7th para. set
1)
0 1 000 -- 0.1 ms
1508* Time const., setpo. filter 8th para. set
1)
0 1 000 -- 0.1 ms
1512* Standard max speed 2nd para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1516* Standard max speed 3rd para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1520* Standard max speed 4th para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1524* Standard max speed 5th para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1528* Standard max speed 6th para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1532* Standard max speed 7th para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1536* Standard max speed 8th para. set
1)
10 000 99 999 999 --
mm Inch Deg.
–––– –––– ––––
min min min
1540* Exact stop limit coarse 2nd para. set
1)
40 16 000
2)
MS units
1544* Exact stop limit coarse 3rd para. set
1)
40 16 000
2)
MS units
1548* Exact stop limit coarse 4th para. set
1)
40 16 000
2)
MS units
1552* Exact stop limit coarse 5th para. set
1)
40 16 000
2)
MS units
1556* Exact stop limit coarse 6th para. set
1)
40 16 000
2)
MS units
1560* Exact stop limit coarse 7th para. set
1)
40 16 000
2)
MS units
1564* Exact stop limit coarse 8th para. set
1)
40 16 000
2)
MS units
1568* Exact stop limit fine 2nd para. set
1)
10 16 000
2)
MS units
1572* Exact stop limit fine 3rd para. set
1)
10 16 000
2)
MS units
1576* Exact stop limit fine 4th para. set
1)
10 16 000
2)
MS units
1580* Exact stop limit fine 5th para. set
1)
10 16 000
2)
MS units
1584* Exact stop limit fine 6th para. set
1)
10 16 000
2)
MS units
1588* Exact stop limit fine 7th para. set
1)
10 16 000
2)
MS units
1592* Exact stop limit fine 8th para. set
1)
10 16 000
2)
MS units
_______
1) SW4 and higher
2) SW4.4 and higher: 99 999 999
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–39
SINUMERIK 840C (IA)
