1 NC/Drive Machine Data 10.94
1.11.1 611A drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
175 Gain factor x
n
- characteristic
Motor 1
Depends
on motor
300 -- %
176 Breakdown torque
reduction factor Motor 1
100 150 -- %
179 Selection min/max memory 0 2 -- HEX
180 Enable motor switchover 0 1 -- HEX
181 Address for min/max memory 0D02 FFFF -- HEX
182 Minimum value min/max
memory
-- -- -- HEX
183 Maximum value min/max
memory
-- -- -- HEX
185 Address for monitoring 1 0C06 FFFF -- HEX
186 Threshold for monitoring 1 0000 FFFF -- HEX
187 ON-delay
Monitoring 1
0 10.00 -- s
188 Drop delay
Monitoring 1
0 10.00 -- s
189 Hysteresis monitoring 1 1 FFFF -- HEX
190 Address for monitoring 2 0C06 FFFF -- HEX
191 Threshold for monitoring 2 0000 FFFF -- HEX
192 ON-delay
Monitoring 2
0 10.00 -- s
193 Drop delay
Monitoring 2
0 10.00 -- s
194 Hysteresis monitoring 2 1 0FFFF -- HEX
195 Lower adaptation speed
Motor 1
1000 (Max. speed)
-2
-- rev/min
196 Upper adaptation speed
Motor 1
1200 (Max. speed) -- rev/min
--
198 P gain upper adaptation
speed Motor1
24.0 120.0 -- --
199 Reduction factor P-gain
Motor 1
100 200 -- %
1–56 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
