10.94 1 NC/Drive Machine Data
1.11.1 611A drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
201 Reset time upper adaptation
speed Motor 1
80 6000 -- ms
202 Reduction factor reset time
Motor 1
100 200 -- %
203 Selection adaption speed
controller Motor 1
0 7 -- --
206 Selection transient recorder 0 1 -- HEX
207 Set transient recorder 0 10 -- HEX
208 Address for start condition 0 FFFF -- HEX
209 Threshold for start condition 0 FFFF -- HEX
210 Address for stop condition 0 FFFF -- HEX
211 Threshold for stop condition 0 FFFF -- HEX
212 Address signal 1 0C00 FFFF -- HEX
213 Address signal 2 0C04 FFFF -- HEX
214 Start output of recording 0 1 -- HEX
215 Shift factor signal 1 0 15 -- --
216 Shift factor signal 2 0 15 -- --
217 Trigger signal 1 0000 FFFF -- HEX
218 Trigger signal 2 7FFF FFFF -- HEX
219 Motor moment of inertia
Motor 2
Depends
on motor
32.000 -- kg m
2
220 Motor rated output
Motor 2
Depends
on motor
150.0 -- KW
221 Motor rated current
Motor 2
Depends
on motor
200.0 -- A
222 Motor rated voltage
Motor 2
Depends
on motor
500.0 -- V
223 Motor rated speed
Motor 2
Depends
on motor
4096 -- rev/min
224 Motor rated frequency
Motor 2
Depends
on motor
409.6 -- Hz
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–57
SINUMERIK 840C (IA)
