1 NC/Drive Machine Data 10.94
1.11.1 611A drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
225 Motor no-load voltage
Motor 2
Depends
on motor
500.0 -- V
226 Motor no-load current
Motor 2
Depends
on motor
200.0 -- A
227 Stator resistance cold
Motor 2
Depends
on motor
32767 -- m
228 Rotor resistance cold
Motor 2
Depends
on motor
32767 -- m
229 Stator leakage reactance
Motor 2
Depends
on motor
32767 -- m
230 Rotor leakage reactance
Motor 2
Depends
on motor
32767 -- m
231 Magnetizing reactance
Motor 2
Depends
on motor
65535 -- m
232 Upper speed X
n
- characteristic
Motor 2
Depends
on motor
10000 -- rev/min
233 Speed at start of field
weakening Motor 2
Depends
on motor
6000 -- rev/min
234 Motor maximum speed
Motor 2
Depends
on motor
20000 -- rev/min
235 Gain factor X
n
- characteristic Depends
on motor
300 -- %
236 Breakdown torque reduction
factor Motor 2
100 150 -- %
238 Motor code number
Motor 2
101 332 -- --
241 Programmable message 1 2 20 -- --
242 Programmable message 2 3 20 -- --
243 Programmable message 3 1 20 -- --
244 Programmable message 4 4 20 -- --
245 Programmable message 5 20 20 -- --
246 Programmable message 6 7 20 -- --
247 Control word message 0000 FFFF -- HEX
1–58 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
