Siemens SIMODRIVE 611-D Installation Guide

10.94 1 NC/Drive Machine Data
1.11.1 611A drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
254 Display of active functions
1
-- -- -- HEX
255 Display of active functions
2
-- -- -- HEX
258 Speed for max. motor
operational speed Motor2
Motor
max.
speed
Motor
max.
speed
-- rev/min
260 n
min
for n
act
< n
min
message Motor 2
12 Rated speed -- rev/min
261 Creep speed pulse
suppression Motor 2
Rated
speed
256
Rated speed
-- rev/min
262 n
x
for n
act
< n
x
message Motor 2
6000 Motor max.
speed
-- rev/min
263 Tolerance band for
n
set
= n
act
message Motor 2
20 Rat. speed
-1
16
-- rev/min
264 Speed limitation
Motor 2
Max.
speed
Motor max.
speed
-- rev/min
265 P-gain speed controller
Motor 2
32.0 120.0 -- --
266 Reset time speed controller
Motor 2
20 6000 -- ms
267 Switchover speed motor
encoder evalution Motor 2
32000 32000 -- rev/min
268 Hysteresis MD 267
Motor 2
50 500 -- rev/min
269 1st torque limiting value
Motor 2
100 180 -- %
270 Generative limitation
Motor 2
100 100 -- %
271 2nd torque limiting value
Motor 2
50 100 -- %
272 Switchover speed for MD 270
Motor 2
500 Motor max.
speed
-- rev/min
273 Hysteresis MD 272
Motor 2
20 Motor max.
speed
-- rev/min
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–59
SINUMERIK 840C (IA)
