09.95 1 NC/Drive Machine Data
1.11.2 611D drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1122 Natural frequency reference
model current closed-loop
0 8000 -- Hz
1123 Damping reference model
current closed-loop
1 5 -- --
1200 Selection current setpoint filter 1 4 -- --
1201 Type current setpoint filter Low pass Band stop -- --
1202 Natural frequency current
setpoint filter 1
2000 8000 -- Hz
1203 Damping current setpoint
filter 1
0,7 5 -- --
1204 Natural frequency current
setpoint filter 2
0 8000 -- Hz
1205 Damping current setpoint
filter 2
1.0 5 -- --
1206 Natural frequency current
setpoint filter 3
0 8000 -- Hz
1207 Damping current setpoint
filter 3
1.0 5 -- --
1208 Natural frequency current
setpoint filter 4
0 8000 -- Hz
1209 Damping current setpoint
filter 4
1.0 5 -- --
1210 Block frequency current
setpoint filter 1
3500.0 7999.0 -- Hz
1211 Bandwidth current setpoint
filter 1
500 1000 -- Hz
1213 Block frequency current
setpoint filter 2
3500.0 7999.0 -- Hz
1214 Bandwidth current setpoint
filter 2
500 1000 -- Hz
1216 Block frequency current
setpoint filter 3
3999.0 7999.0 -- Hz
1217 Bandwidth current setpoint
filter 3
100 1000 -- Hz
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–63
SINUMERIK 840C (IA)
