1 NC/Drive Machine Data 09.95
1.11.2 611D drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1219 Block frequency current
setpoint filter 4
3999.0 7999.0 -- Hz
1220 Bandwidth current setpoint
filter 4
100 1000 -- Hz
1400 Motor rated speed 1500 6000 -- rev/min
1401 Maximum motor operational
speed
1500 7200 rev/min
1402 Reduction factor max. motor
speed set-up mode
1 100 -- %
1403 Creep speed pulse
suppression
0 7200 -- rev/min
1404 Timer pulse suppression 100 1000 -- ms
1405 Monitoring speed
Motor
110 110 -- %
1407 P gain speed controller 0.3 100000 -- Nm/s-1
1408 P gain upper adaptation speed 0.3 100000 -- Nm/s-1
1409 Reset time speed controller 10 500 -- ms
1410 Reset time upper adaptation
speed
10 500 -- ms
1411 Lower adaptation speed
threshold
0 7200 -- rev/min
1412 Upper adaptation speed
threshhold
0 7200 -- rev/min
1413 Selection adaptation speed
controller parameter
0 1 -- --
1414 Natural frequency reference
model rot. speed closed-loop
0 8000 -- Hz
1415 Damping reference model
speed closed-loop
1 5 -- --
1416 Symmetr. reference model
speed closed- loop
0 1.0 -- --
1417 n
x
for n
act
< n
x
signal 6 000.0 7200 -- rev/min
1418 n
min
for n
act
< n
min
signal 0.0 7200 -- rev/min
1421 Time constant for integrator
feedback
0.0 1000.0 -- MS
1–64 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
