07.97 1 NC/Drive Machine Data
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1210 Stop frequency current setpoint
filter 1
3 500.0 7 999.0 – Hz
1211 Bandwidth current setpoint
filter 1
500.0 7 999.0 – Hz
1212 Bandwidth counter current
setpoint filter 1
0.0 7 999.0 – Hz
1213 Stop freq. current setp. filter 2 3 500.0 7 999.0 – Hz
1214 Bandwidth current setpoint
filter 2
500.0 7 999.0 – Hz
1215 Bandwidth counter current
setpoint filter 2
0.0 7 999.0 – Hz
1216 Stop freq. current setp. filter 3 3 500.0 7 999.0 – Hz
1217 Bandwidth current setpoint
filter 3
500.0 7 999.0 – Hz
1218 Bandwidth counter current
setpoint filter 3
0.0 7 999.0 – Hz
1219 Stop freq. current setp. filter 4 3 500.0 7 999.0 – Hz
1220 Bandwidth current setp. filter 4 500.0 7 999.0 – Hz
1221 Bandwidth counter current
setpoint filter 4
0.0 7 999.0 – Hz
1230 1st torque limiting value 100.0 900.0 – %
1231 2nd torque limiting value 100.0 100.0 – %
1232 Switching speed from MD 1230
to MD 1231
6 000.0 50 000.0 – rev/min
1233 Generator limitation 100.0 100.0 – %
1234 Hysteresis MD 1232 50.0 1 000.0 – rev/min
1235 1st power limit 100.0 900.0 – %
1236 2nd power limit 100.0 100.0 – %
1237 Generative maximum output 100.0 500.0 – kW
1238 Current limit 150.0 300.0 – %
1239 Torque limit setup mode 1.0 100.0 – %
1245 Threshold speed-dependent
torque setpoint smoothing
0.0 50 000.0 – rev/min
