1 NC/Drive Machine Data 08.96
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1136 Motor no-load current 0.0 500.0 – A
1137 Stator resistance cold 0.0 20.0 –
1138 Rotor resistance cold 0.0 20.0 –
1139 Stator leakage reactance 0.0 100.0 –
1140 Rotor leakage reactance 0.0 100.0 –
1141 Magnetizing reactance 0.0 1 000.0 –
1142 Speed at start of field
weakening
0.0 50 000.0 – rev/min
1143 Upper speed L
h
characteristic 0.0 50 000.0 – rev/min
1144 Gain factor L
h
characterisitc 100.0 500.0 – %
1145 Breakdown torque reduction
factor
100.0 1 000.0 – %
1146 Maximum motor speed 1500.0 50 000.0 – rev/min
1147 Speed limitiation 7 000.0/
8 000.0
50 000.0 – rev/min
1150 P gain flux controller 400.0 100 000.0 – A/Vs
1151 Reset time flux controller 10.0 500.0 – ms
1160 Oper. speed flux acquisition
(from SW 5)
1 500.0 50 000.0 -- rev/min
1161 DC link fixed voltage 600 700 – V
1190 Torque limit value 100.0 10 000.0 – Nm
1191 Adaptation factor servo limit
torque
1.0 100.0 – –
1200 No. of current setpoint filters 1 4 – –
1201 Type of current setpoint filter Low pass Band stop – –
1202 Natural frequency current
setpoint filter 1
2 000.0 8 000.0 – Hz
1203 Damping current setp. filter 1 0.7 5.0 – –
1204 Natural frequency current
setpoint filter 2
0.0 8 000.0 – Hz
1205 Damping current setp. filter 2 1.0 5.0 – –
1206 Natural frequency current
setpoint filter 3
0.0 8 000.0 – Hz
1207 Damping current setp. filter 3 1.0 5.0 – –
1208 Natural frequency current
setpoint filter 4
0.0 8 000.0 – Hz
1209 Damping current setp. filter 4 1.0 5.0 – –
1–68 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
