7.2 Checklists
Checklists for commissioning linear motors
Before starting any work, get to know and understand the safety instructions and observe the
following checklists.
Table 7-1 Checklist (1) - general checks
Check OK
Are all of the necessary components of the con󹪝gured drive line-up available, correctly dimensioned, in‐
stalled and connected?

Is the manufacturer's documentation for the system components (e.g. drive system, brake, encoder, brake)
available?

If the 1FN3 linear motor is to be fed from a SINAMICSS120 drive system:
Is the following, current SINAMICS documentation available?
• SINAMICS S120 Commissioning Manual
• SINAMICS S120 Getting Started
• SINAMICS S120 Function Manual
• List Manual SINAMICSS120/150

If the 1FN3 linear motor is to be fed from a SINAMICSS120 drive system:
Was the Chapter "Checklists for commissioning SINAMICS S" in the SINAMICS S120 Commissioning Manual
carefully observed?

If the 1FN3 linear motor is to be fed from a SINAMICSS120 drive system:
Is the motor type to be commissioned known?
(e.g.1FN3_ _ _–_ _ _ _ _– _ _ _ _)

If the 1FN3 linear motor is to be fed from a SINAMICSS120 drive system:
If it involves a "third-party motor", are the following motor data known as a minimum?
(A "third-party motor" is a motor that is not (yet) saved as standard in the Siemens commissioning software.)
• Rated motor current
• Motor rated velocity
• Motor pole distance
• Motor force constant
• Maximum motor speed
• Maximum motor current
• Motor limit current
• Motor weight
• Phase resistor of the motor winding is cold
• Phase inductance of winding

Are the environmental conditions in the permissible range? 
Commissioning
7.2Checklists
Naturally-Cooled 1FN3 Linear Motors
Operating Instructions, 06/2023, A5E52220465B AB 101
