– Then remove the spacer foil from the air gap without applying any force.
/LQHDUJXLGH
VHFRQGDU\VHFWLRQWUDFN
3ULPDU\VHFWLRQ
6OLGH
❒
5.3.6 Assembling individual motor components
5.3.6.1 Installing the secondary sections
WARNING
There is a high risk of crushing 󹪝ngers etc. when handling unpacked secondary sections!
Secondary sections and materials that can be magnetized can suddenly slam together
unintentionally. Two secondary sections can also unintentionally slam together.
• Heed the warning information "Risk of crushing caused by permanent magnets of the
secondary section" in Chapter "Safety guidelines relating to installation (Page57)".
Installation
5.3Procedure when installing the motor
Naturally-Cooled 1FN3 Linear Motors
Operating Instructions, 06/2023, A5E52220465B AB 69
