• To free jammed parts of the body (e.g. hands, 󹪝ngers, feet), pull apart components that are
clamped together.
– Do this using the non-magnetic hammer to drive the non-magnetic wedges into the
separating rift.
– Release the jammed body parts.
• If necessary, call the emergency medical service or an emergency physician.
Material damage caused by strong magnetic 󹪝elds
NOTICE
Data loss caused by strong magnetic 󹪝elds
If you are close to a secondary section (< 150 mm) any magnetic or electronic data medium as
well as electronic devices that you are carrying can be destroyed. For example, credit cards, USB
sticks, 󹪞oppy disks and watches are at risk.
• Do not carry any magnetic/electronic data media and no electronic devices when you are
close to a secondary section!
3.1.3 Technical features
Table 3-1 Standard version of the naturally cooled 1FN3 linear motor
Technical feature Design
Motor type Permanently excited synchronous linear motor
Type of construction Individual components
Degree of protection according to
DINEN60034-5
• Primary section: IP23
• Mounted motor: The degree of protection depends on the machine design and
must therefore be realized by the machine manufacturer; minimum requirement:
IP23
Cooling method Natural cooling via cooling ribs and the contact surface between the primary section
and machine
Thermal motor protection Temperature sensor in the primary section
• 1x PTC thermistor triplet with response threshold +120°C
(according to DIN44081/44082)
Evaluation
• According to the SINAMICS S120 Equipment Manual via
– Sensor Module SME120/SME125 or
– TM120
2nd rating plate Enclosed separately
Rating plate for secondary sections Enclosed separately
Description
3.1Technical features and ambient conditions
Naturally-Cooled 1FN3 Linear Motors
Operating Instructions, 06/2023, A5E52220465B AB 33
