Siemens SIMOTICS L-1FN3 User Manual

6.6 Motor circuit diagram
6.6.1 Circuit diagram, naturally cooled linear motor L-1FN3
The circuit diagram of the primary section looks like this:
5151
țțț
1&
876
5FNQ4
Figure6-5 Circuit diagram for primary section
6.7 Shielding, grounding, and equipotential bonding
Note
Unshielded 󹪞exible leads as connecting cables
As a result of the inherent design, naturally cooled SIMOTICS L‑1FN3 linear motors have
unshielded 󹪞exible leads as connecting cables.
The EMC behavior of these motors depends on the customer-speci󹪝c installation conditions.
Apply EMC measures against electromagnetic interference 󹪝elds of the motor.
Electrical connection
6.7Shielding, grounding, and equipotential bonding
Naturally-Cooled 1FN3 Linear Motors
Operating Instructions, 06/2023, A5E52220465B AB 95
