Secondary section
• Secondary section
• A nameplate included as a separate item
• Accessory pack note (safety accessory pack)
• Safety warning instructions (pictograms)
Note
Nameplates for secondary sections
The nameplates for secondary sections are not suitable for applying to a secondary section or to
the secondary section cover. Apply the nameplates for secondary sections in a clearly visible
position next to the secondary section track or in the vicinity of the motor.
3.4.2.2 Supplied pictograms
Primary sections
To identify hazards, warning signs in the form of permanent adhesive stickers are enclosed
with all primary sections in the packaging:
Table 3-6 Warning signs included with primary sections according to BGV A8 andENISO7010 and
their meaning
Sign Meaning Sign Meaning
Warning against
hot
surface
(W017)
Warning against
electric
voltage
(W012)
The following safety instructions are attached at the signal port of the primary section:
Table 3-7 Safety instructions for temperature protection according to BGV A8 and ENISO7010 and
their signicance
Sign Meaning Sign Meaning
General
warning sign
(W001)
Observe
instruction
(M002)
Description
3.4Design
Naturally-Cooled 1FN3 Linear Motors
42 Operating Instructions, 06/2023, A5E52220465B AB
