Protective mat with magnetic self-holding function

Use the protective mat with the magnetic self-holding function as mounting or removal aid for

secondary sections. The protective mat with magnetic self-holding function protects you and

the secondary sections against the consequences of the sudden forces of attraction of the

secondary section in the immediate vicinity.

NOTICE

Damage to the protective mat with magnetic self-holding function

If you subject the protective mat with magnetic self-holding function to moisture and/or

excessively high storage temperatures, the bonded connection between the foam rubber mat

and the metal sheet will be damaged.

• Ensure that the conditions for storage and transport from Chapter "Preparations for use

(Page49)" are complied with for the protective mat with magnetic self-holding function.

NOTICE

No motor operation when the protective mat with magnetic self-holding function is

placed down

The motor or the machines can be damaged if you operate the motor with the protective mat

placed down on secondary sections.

• Remove the protective mat with magnetic self-holding function before commissioning the

motor.

If the original packaging for the secondary sections is not available, then you can use the

protection mat as follows:

• For securely placing down secondary sections

• For brie󹪞y storing secondary sections outside the machine, e.g. when carrying out repairs

and maintenance work

Any other use is not as intended.

The original undamaged packaging is the preferred choice when transporting and storing

secondary sections.

Correct packaging o󹪜ers better protection than the protective mat with magnetic self-holding

function against sudden forces of attraction of the secondary section that can occur in the

immediate vicinity. Further, when correctly packaged, you are protected against hazardous

motion when storing and moving the secondary section.

Introduction

1.5Important product information

Naturally-Cooled 1FN3 Linear Motors

16 Operating Instructions, 06/2023, A5E52220465B AB
