SIMOTION D4x5-2
Manual, 11/2010
31
Operation (hardware)
2
2.1 Overview of operator control and display elements
The following figure shows the arrangement of the operator control and display elements of a
SIMOTION D4x5-2.
2SHUDWRUFRQWURO
DQGGLVSOD\
HOHPHQWV
$UHDSURWHFWHGE\
EODQNLQJFRYHU
Figure 2-1 Position of operator control and display elements
The lower part of the operator control and display elements has a blanking cover during
operation. This cover is removed for service work.
