6.3 TB30 terminal board
SIMOTION D4x5-2
Manual, 11/2010
91
CAUTION
The common-mode range must not be infringed.
The analog differential voltage signals can have a maximum offset voltage of ±30 V with
respect to the ground potential. If the range is infringed, incorrect results may occur during
analog/digital conversion.
6.3.3.6 Working with analog inputs
The following reference contains more information about analog inputs:
● /IH1/
SINAMICS S120 Commissioning Manual.
● /GH1/
SINAMICS S120 Control Units and Additional System Components Manual
6.3.3.7 Commissioning
Information about commissioning can be found in the SIMOTION D4x5-2 Commissioning and
Hardware Installation Manual.
6.3.4 Technical Specifications
Table 6- 9 Technical data of the TB30
Unit Value
Electronic power supply:
- Voltage
- Current via the option slot of the
D4x5-2
(without digital outputs)
- Power loss
V
DC
A
DC
W
24 (20.4 ... 28.8)
0.05
< 3
Response time The response time of digital inputs/outputs and analog inputs/outputs depends
on the evaluation on the control unit (see function diagram).
References: SINAMICS S120/S150 List Manual, Chapter "Function diagrams"
Dimensions (H x W x D), approx. mm 25 x 95 x 143
Weight g 100
