Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
68 Manual, 11/2010
Additional references
Recommended power supply units and tables for calculating the current consumption for the
assembly with SINAMICS S120 modules can be found in the "Control cabinet installation
and EMC booksize" chapter in the
SINAMICS S120 Booksize Power Units
Manual.
4.5 Interfaces and performance features
Memory for system data
Table 4- 7 Memory for system data and the memory size
Data Memory size
SIMOTION D445-2 DP/PN
Memory size
SIMOTION D455-2 DP/PN
Diagnostics buffer (protected
against power failure)
200 messages (SIMOTION)
200 messages (SINAMICS
Integrated)
200 messages (SIMOTION)
200 messages (SINAMICS
Integrated)
RAM (working memory)
1)
128 MB 256 MB
RAM disk (load memory) 50 MB 70 MB
Retentive memory 512 KB 512 KB
Persistent memory (user data
on CF)
2)
300 MB 300 MB
1)
A separate 20 MB of working memory is available for Java applications.
2)
These figures relate to CF cards with a capacity of 1 GB. If the "Upgrade SIMOTION devices"
function is used, the downgrade option requires CF cards with double the memory requirement for
"each switch position". The 300 MB persistent memories can therefore only be achieved with
CF cards with at least 1 GB memory capacity.
PLC and motion control performance
Table 4- 8 Maximum number of axes and minimum cycles for D4x5-2
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Maximum number of axes 64 128
Minimum PROFIBUS cycle 1 ms 1 ms
Minimum PROFINET
transmission cycle
0.25 ms 0.25 ms
Minimum servo/interpolator
cycle clock
0.5/0.25 ms
1)
0.5/0.25 ms
1)
1)
Explanation:
●
0.5 ms in conjunction with SINAMICS S120 (incl. SINAMICS Integrated / CX32-2)
●
0.25 ms in conjunction with SERVOfast and IPOfast for high-speed I/O processing or high-
performance hydraulic applications. The sensors and actuators are connected via high-speed
PROFINET IO I/O modules.
