Siemens SIMOTION D4 Series User Manual

Interfaces
3.4 PROFINET IO interface
SIMOTION D4x5-2
Manual, 11/2010
45
3 RXP I Ethernet
receive
differential
signal
DB+ B Bidirectional
pair B+
4 - - - - - - Reserved, do
not use
DC+ B Bidirectional
pair C+
5 - - - - - - Reserved, do
not use
DC B Bidirectional
pair C-
6 RXN I Ethernet
receive
differential
signal
DB- B Bidirectional
pair B-
7 - - - - - - Reserved, do
not use
DD+ B Bidirectional
pair D+
8 - - - - - - Reserved, do
not use
DD- B Bidirectional
pair D-
I = Input; O = Output; B = Bidirectional
1)
Autocrossing functionality (if required, transmit and receive lines switch over)
Note
The MAC addresses are imprinted on an adhesive label that is located behind the protective
cover and can be seen from the front.
3.4 PROFINET IO interface
PROFINET is an open component-based industrial communication system using Ethernet
for distributed automation systems.
SIMOTION D4x5-2 DP/PN has a PROFINET interface with three ports (X150 P1-P3)
onboard. The PROFINET interface supports operation of a SIMOTION D4x5-2 DP/PN as an
IO controller and/or as an I device.
