Supplementary system components
6.5 Terminal module TM31
SIMOTION D4x5-2
106 Manual, 11/2010
Data SIMOTION CX32-2
Output delay, typ./max. (hardware)
1)
L -> H: 150 µs / 400 µs
H -> L: 75 µs / 100 µs
Switching frequency of the outputs, max.
With resistive load
100 Hz
With inductive load
2 Hz
With lamp load
11 Hz
Maximum lamp load 5 W
Short-circuit protection Yes
1)
Data for: Vcc = 24 V; load 48 Ohm; H = 90% V
out
, L = 10% V
out
2)
The digital inputs are protected against polarity reversal up to -30 V
3)
The values were not available at the time for going to press. Current information is
available at: (http://support.automation.siemens.com/WW/view/en/27585482
)
6.5 Terminal module TM31
Properties of the TM31
With the TM31 terminal module, the number of available digital inputs/digital outputs and the
number of analog input/analog outputs within a drive system can be expanded. The TM31 is
connected via DRIVE-CLiQ. It has two DRIVE-CLiQ interfaces for this.
The TM31 contains the following terminals:
Table 6- 28 Interface overview
Interface Quantity
Digital inputs 8
Bidirectional inputs/outputs 4
Relay outputs with changeover contact 2
Analog inputs 2
Analog outputs 2
Temperature sensor input (KTY84-130 or PTC) 1
CAUTION
The 50 mm clearances above and below the components must be observed.
