Supplementary system components
6.4 CX32-2 controller extension
SIMOTION D4x5-2
100 Manual, 11/2010
Additional references
For information on configuring the DI/DOs as freely addressable I/Os or as measuring inputs,
see the
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual.
For information on the configuration and function of the measuring input, output cam, and
cam track technology objects, refer to the
SIMOTION Output Cams and Measuring Inputs
Function Manual.
6.4.2.5 Power supply
Application
This interface is provided exclusively for connection of an external power supply.
Note
When using external power supplies (e.g. SITOP), the ground potential must be connected
with the protective ground terminal (PELV).
Characteristics of the interface
Table 6- 17 Interface X124
Characteristics Type
Connector type Combicon
Connection possibility Up to 2.5 mm
2
Max. current carrying capacity incl. loop-through 20 A
Max. cable length 10 m
Interface assignments
Table 6- 18 Power supply X124
Pin Signal name Meaning
1 P24 24 V power supply
2 P24 24 V power supply
3 M Ground
4 M Ground
