Technical data of the D4x5-2
4.3 Dimensions and weights
SIMOTION D4x5-2
66 Manual, 11/2010
Ambient conditions Application range Comments
Chemically active environmental conditions
Class 3C1 according to EN 60721-3-3
Mechanically active environmental conditions
Class 3S1 according to EN 60721-3-3,
conductive dust not permitted
1)
Details can be found in the
SINAMICS S120 Control Units and Supplementary System
Components
Manual
Other data
Table 4- 3 Other data
Data
Degree of protection according to EN 60529
(IEC 60529)
IP 20
Pollution degree 2 according to EN 60 664-1
4.3 Dimensions and weights
Dimensions and weights
Table 4- 4 Dimensions and weight of a SIMOTION D4x5-2
Parameter SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Dimensions W x H x D [mm]
Without fastening using spacers,
without fan/battery module
50 x 380 x 230 50 x 380 x 230
With fastening using spacers,
without fan/battery module
50 x 380 x 270 50 x 380 x 270
Weight [g]
- Without packaging
- With packaging
Approx. 4.4 kg
Approx. 5.0 kg
Approx. 4.4 kg
Approx. 5.0 kg
Note
With the D445-2 DP/PN and D455-2 DP/PN, the spacers can only be removed with the
"external air cooling" installation method. In this installation method, the cooling fins are
inserted through a cutout in the rear cabinet panel.
For further details, see the
SIMOTION D4x5-2
Commissioning and Hardware Installation
Manual.
