Siemens SIMOTION D4 Series User Manual

SIMOTION D4x5-2
Manual, 11/2010
39
Interfaces
3
3.1 Interface overview
This section describes the interfaces of the SIMOTION D4x5-2.
Available interfaces
Table 3- 1 Overview of available interfaces
Interface Name Connector type
DRIVE-CLiQ interface X100 DRIVE-CLiQ socket
DRIVE-CLiQ interface X101 DRIVE-CLiQ socket
DRIVE-CLiQ interface X102 DRIVE-CLiQ socket
DRIVE-CLiQ interface X103 DRIVE-CLiQ socket
DRIVE-CLiQ interface X104 DRIVE-CLiQ socket
DRIVE-CLiQ interface X105 DRIVE-CLiQ socket
Ethernet interface PN/IE X127 P1 RJ45 socket connector
Ethernet interface PN/IE-NET X130 P1 RJ45 socket connector
PROFINET IO interface PN X150 (P1, P2, P3) RJ45 socket connector
Digital inputs/outputs X122, X132, X142 Mini Combicon, 3.5 mm
3x14-pin
Power supply connector X124 Combicon, 4-pin
PROFIBUS DP interface X126 9-pin Sub-D socket
PROFIBUS DP/MPI interface X136 9-pin Sub-D socket
Measuring sockets (T0, T1, T2, and M) X141 4-pin, socket
SIMOTION CF plug-in X109 CompactFlash Card connector
Fan/battery module interface X190 Fan/battery module
1. USB interface X125 USB socket
2. USB interface X135 USB socket
Option slot Sockets
