Operation (hardware)
2.3 7-segment and LED displays
SIMOTION D4x5-2
38 Manual, 11/2010
Note
While the SIMOTION D4x5-2 is ramping up, all LEDs are briefly illuminated in yellow.
7-segment display
The 7-segment display provides further status information in addition to the LED displays.
The status "6" and a flashing "." indicate that the D4x5-2 has ramped up and communication
has been established to the SINAMICS Integrated.
Additional information
You can carry out a detailed diagnosis using a PG/PC and the Engineering System.
Information on the diagnostics via LED displays can also be found in the
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual and in the online help of this chapter via
the link under the menu instructions.
