Interfaces
3.5 Digital inputs/outputs
SIMOTION D4x5-2
Manual, 11/2010
53
Pin Designation
1)
Signal type
2)
Notes
13 IN/OUT 7 B Digital input/output 7 (can be used as input of a measuring
input or output of an output cam)
14 M GND Ground
1)
IN/OUT: Bidirectional digital input/output; M: Electronic ground
2)
B = Bidirectional; GND = Reference potential (ground)
3.5.2 Using the digital inputs/outputs
Connecting sensors and actuators
Digital inputs and digital outputs can be used to connect various sensors and actuators to
the three 14-pin X122, X132 and X142 front connectors.
The following types of digital inputs/outputs are available:
● Digital inputs (DI)
● Bidirectional digital inputs/outputs (DI/DO, IN/OUT)
Bidirectional digital inputs and outputs can be configured individually as digital inputs or
outputs.
Assignment of the inputs/outputs to functions can be parameterized as required. Special
functions (e.g. input of measuring input and output for output cam) can be assigned to the
inputs/outputs.
The digital inputs/outputs on the X122 and X132 front connectors can be used by either
SIMOTION or SINAMICS (e.g. as enable signal for a drive).
The digital inputs/outputs on the X142 front connector are firmly allocated to SIMOTION.
Table 3- 13 Use of the digital inputs/outputs
DI 0-7, DI 17, DI 18,
DI 20, DI 21 (X122,
X132)
DI/DO 8-15
(X122, X132)
IN/OUT 0-7
(X142)
Galvanic isolation Electrically isolated
(ground reference M1
or M2)
Non-isolated
(ground reference M)
Non-isolated
(ground reference M)
Use as:
Freely addressable
I/Os for SIMOTION
Yes Yes Yes
I/Os that are assigned
to the drive
Yes Yes No
Measuring inputs
No Yes
(global and local
measuring inputs)
Yes
(global measuring
inputs)
