Supplementary system components
6.4 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 11/2010
105
Digital inputs
Table 6- 26 Digital inputs on SIMOTION CX32-2
Data SIMOTION CX32-2
Digital inputs 6
 Rated value
24 VDC
 For signal "1"
15 ... 30 V
 For signal "0"
2)
-3 ... +5 V
Galvanic isolation Yes, in groups of 6
1)
Current consumption typ. at High level 9 mA at 24 V
Input delay, typical (hardware) L -> H: 50 µs
H -> L: 150 µs
1)
The reference potential is terminal M1
2)
The digital inputs are protected against polarity reversal up to -30 V
Digital inputs/outputs (parameterizable)
Table 6- 27 Digital inputs/outputs on SIMOTION CX32-2
Data SIMOTION CX32-2
Number of digital inputs/outputs 4
 Max. 4 as inputs of measuring inputs
 Max. 0 as outputs of output cams / fast
DOs
If used as an input:
 Input voltage, rated value
24 VDC
 Input voltage, for signal "1"
15 ... 30 V
 Input voltage, for signal "0"
2)
-3 ... +5 V
Galvanic isolation No
Current consumption typ. at signal level "1" 9 mA at 24 V
Input delay, typical (hardware):
For DI/DO 08 - 11
L -> H: 5 µs
H -> L: 50 µs
Input of measuring input, accuracy
(reproducibility)
3)
If used as an output
 Rated load voltage, permissible range
24 VDC, 20.4 ... 28.8 V
 Galvanic isolation
No
 Current load, max.
500 mA per output
 Residual current, max.
2 mA
