Supplementary system components
6.4 CX32-2 controller extension
SIMOTION D4x5-2
104 Manual, 11/2010
Parameter Values
Degree of protection according to EN 60529
(IEC 60529)
IP20
Pollution degree 2 according to EN 60 664-1
1)
The max. installation altitude for SINAMICS S120 drive components (motor modules, etc.) is 4000
m.
Details can be found in the SINAMICS S120 Control Units and Supplementary System
Components Manual.
Integrated drive control
Table 6- 23 Controls for integrated drives
Data SIMOTION CX32-2
Max. number of axes for integrated drive
control (servo/vector/
V
/
f
)
6 / 6 / 12 (alternative)
Drive control based on CU320-2, firmware version
4.x
Communication
Table 6- 24 Interface communication
Data SIMOTION CX32-2
DRIVE-CLiQ interfaces 4
General technical data
Table 6- 25 Technical data (general)
Data SIMOTION CX32-2
Power supply
Rated value
Permissible range
24 VDC
(20.4 ... 28.8 V)
Current consumption, typically
1)
300 mA
Starting current, typical 1.6 A
Power loss, typical 7 W
Power loss, max. 14 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE-CLiQ interface
