Interfaces
3.3 Ethernet interfaces
SIMOTION D4x5-2
44 Manual, 11/2010
Note
The two interfaces support Industrial Ethernet (IE). The designation of the interfaces
PN/IE-NET or PN/IE has already been designed for the support of PROFINET basic services
(e.g. DCP, LLDP, SNMP) via these interfaces in a future version. These PROFINET basic
services provide uniform functions for the address assignment and diagnostics, but do not
provide PROFINET IO communication for the connection of drives or I/O modules, for
example.
Additional references
Detailed information on the states of the status LEDs can be found in the
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, Diagnostics chapter.
Interface characteristics
Table 3- 5 X127 P1 and X130 P1
Characteristic Type
Connector type RJ45 socket connector
Cable type Industrial Ethernet cable
4- and 8-wire cables can be used for 10/100 Mbit/s
8-wire cables must be used for 1000 Mbit/s
Max. cable length 100 m
Autocrossing Yes
Dust protection blanking
plugs for sealing unused
Ethernet ports
Five blanking plugs contained in the D4x5-2 scope of delivery
Blanking plugs (50 pcs) order number: 6SL3 066-4CA00-0AA0
Miscellaneous X127 P1 and X130 P1 are full-duplex 10/100/1000 Mbit/s Ethernet
ports
Pin assignment
Table 3- 6 Ethernet interfaces (X120 P1 and X130 P1)
Assignment in 10/100 Mbit mode Assignment in 1 Gbit mode Pin
Signal name
1)
Signal type Meaning Signal name
1)
Signal type Meaning
1 TXP O Ethernet
transmit
differential
signal
DA+ B Bidirectional
pair A+
2 TXN O Ethernet
transmit
differential
signal
DA- B Bidirectional
pair A-
