Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
Manual, 11/2010
69
Integrated drive control
Table 4- 9 Controls for integrated drives
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Max. number of axes for
integrated drive control
(servo/vector/ V / f )
6 / 6 / 12 (alternative) Drive
control based on CU320-2,
firmware version 4.x
6 / 6 / 12 (alternative) Drive
control based on CU320-2,
firmware version 4.x
Communication
Table 4- 10 Interfaces
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
DRIVE-CLiQ interfaces 6 6
Ethernet interfaces 2 2
PROFIBUS interfaces
1)
2 2
PROFINET interfaces
2)
1 interface with 3 ports,
onboard
1 interface with 3 ports, onboard
1)
Supports PROFIBUS DP, isochronous, can be configured either as master or slave
2)
Supports PROFINET IO with IRT and RT, can be configured as PROFINET IO controller and/or
device
Address space
Table 4- 11 Address space
Address space SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Logical I/O address space in KB 16 KB 16 KB
Physical I/O address space in KB
 PROFIBUS (for each interface): Max.
for inputs and outputs respectively:
 PROFINET: Max. for inputs and
outputs respectively:
 1 Kbyte
1)
 4 KB
1)
 1 Kbyte
1)
 4 KB
1)
Permanent process image for
BackgroundTask (I/O variables)
64 bytes 64 bytes
Additional configurable process image for
each cyclic task (I/O variables)
Yes Yes
Address space for each PROFIBUS DP
station
244 bytes 244 bytes
