Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
70 Manual, 11/2010
Address space for each
SINAMICS Integrated/CX32-2
(PROFIBUS Integrated)
512 bytes 512 bytes
Address space for each PROFINET
device
1400 bytes 1400 bytes
1)
When PROFIBUS and PROFINET are used, the total address space applies
Digital inputs
Table 4- 12 Digital inputs on SIMOTION D4x5-2
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Digital inputs 12 12
 Rated value
24 VDC 24 VDC
 For signal "1"
15 ... 30 V 15 ... 30 V
 For signal "0"
2)
-3 ... +5 V -3 ... +5 V
Galvanic isolation Yes, in groups of 6
1)
Yes, in groups of 6
1)
Current consumption typ. at
signal level "1"
9 mA at 24 V 9 mA at 24 V
Input delay, typ. (hardware) L -> H: 50 µs
H -> L: 150 µs
L -> H: 50 µs
H -> L: 150 µs
1)
Reference potential is terminal M1 or M2
2)
The digital inputs are protected against polarity reversal up to -30 V
Digital inputs/outputs (parameterizable)
Table 4- 13 Digital inputs/outputs on SIMOTION D4x5-2
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Digital inputs/outputs 16
 Max. 16 as inputs of
measuring inputs
 Max. 8 as outputs of output
cams / fast DOs
16
 Max. 16 as inputs of
measuring inputs
 Max. 8 as outputs of output
cams / fast DOs
If used as an input
 Input voltage, rated value
24 VDC 24 VDC
 Input voltage, for signal "1"
15 ... 30 V 15 ... 30 V
 Input voltage, for signal "0"
2)
-3 ... +5 V -3 ... +5 V
Galvanic isolation No No
Current consumption typ. at signal
level "1"
9 mA at 24 V 9 mA at 24 V
