Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
Manual, 11/2010
71
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Input delay, typ. (hardware) L -> H: 5 µs
H -> L: 50 µs
L -> H: 5 µs
H -> L: 50 µs
Input of measuring input, accuracy
(reproducibility)
3)
3)
If used as an output
Rated load voltage, permissible
range
24 VDC, 20.4 ... 28.8 V 24 VDC, 20.4 ... 28.8 V
Galvanic isolation
No No
Current load, max.
500 mA per output 500 mA per output
Residual current, max.
2 mA 2 mA
Output delay, typ./max.
(hardware)
1)
L -> H: 150/400 µs
H -> L: 75/150 µs
L -> H: 150/400 µs
H -> L: 75/150 µs
Cam output, accuracy
reproducibility, terminal X142
3)
3)
Switching frequency of the outputs, max.
With resistive load
100 Hz 100 Hz
With inductive load
2 Hz 2 Hz
With lamp load
11 Hz 11 Hz
Short-circuit protection Yes Yes
1)
Specification for Vcc = 24 V, load 48 Ohm, H = 90% V
Out
; L = 10% V
Out
2)
The digital inputs are protected against polarity reversal up to -30 V
3)
The values were not available at the time for going to press.
Current information
can be found at (http://support.automation.siemens.com/WW/view/en/27585482)
Other technical data
Table 4- 14 Fan, non-volatile data backup and approvals
Data SIMOTION D445-2 DP/PN SIMOTION D455-2 DP/PN
Fan Double fan/battery module
included in scope of delivery
Double fan/battery module
included in scope of delivery
Backup time, min.
Charging time, typ.
4 days (real-time clock backup)
A few minutes
4 days (real-time clock backup)
A few minutes
Approvals
cULus
1)
cULus
1)
Marking for Australia
C-Tick mark
1)
C-Tick mark
1)
1)
The approval/marking was not available at the time for going to press. Current information is
available at: http://support.automation.siemens.com/WW/view/en/27585482
