Siemens SIMOTION D4 Series User Manual

Operation (hardware)
2.2 Operator controls
SIMOTION D4x5-2
Manual, 11/2010
35
Service selector switch
The following table shows the possible positions of the Service selector switch. The Service
selector switch positions are explained in the order in which they are arranged on the
SIMOTION D4x5-2.
Table 2- 3 Switch positions of the Service selector switch
Service mode Selector position Meaning
- 0 No service/diagnosis functions activated (default setting).
Delete/restore
non-volatile data
1 When the "Delete/restore non-volatile data" switch setting is
selected, the non-volatile data of the D4x5-2 is first deleted
and then restored along with the contents of the PMEMORY
backup file.
Downgrade
(device update
tool)
B SIMOTION D4x5-2 control units and projects can be updated
using update data created at an earlier point in time. This
update data is generated with the device update tool (Menu:
"Project>Start device update tool" in SIMOTION SCOUT).
If the updating process fails to bring about the desired result,
the update can be rejected by means of the switch position.
This will roll the system back to the previous configuration.
Backing up
diagnostic data
and non-volatile
data
D The diagnostic data and non-volatile data can be backed up in
STOP, STOPU and RUN mode. The advantage of backing up
in RUN mode is the availability of enhanced diagnostic
information (via websites) and TO alarm information.
Note
Alternatively, diagnostics data and non-volatile data can also be backed up via the DIAG
button, see Section DIAG button (Page 36).
Additional references
Detailed information on the individual topics can be found in the following table.
Table 2- 4 References
Subject Reference
Setting of the operating modes

SIMOTION SCOUT Configuration Manual
Upgrading devices (device update tool)

Updating SIMOTION Devices Operating
Instructions and
 SIMOTION D4x5-2 Commissioning and
Hardware Installation Manual
 Creating diagnostics data and
 Saving/restoring non-volatile data
 SIMOTION D4x5-2 Commissioning and
Hardware Installation Manual
