Default Ethernet addresses
The following IP addresses are assigned by default for the Ethernet interface:
Table 6-8
IP address assignment for SIMOTION D410‑2
Interface Use case Default address
X127 P1 PN/
IE
Insert SIMOTION device or
HW Config
IP address:
Subnet mask:
Router address:
Automatic private IP address
169.254.11.22
255.255.0.0
0.0.0.0
SIMOTION D410‑2 in the de‐
livery condition
IP address:
Subnet mask:
Router address:
Automatic private IP address
169.254.11.22
255.255.0.0
0.0.0.0
Note
The IP addresses 192.168.215.240 to 192.168.215.255 are reserved for internal
communication in the SIMOTION D410-2 (subnet mask 255.255.255.240). When configuring
the external Ethernet interface (X127 P1), make sure that the internal addresses are not inside
their network. In IP, the network is defined as an AND link of IP address and subnet mask.
Note
If
you want to go online via Ethernet, you have to make sure that the connection from PG/PC
to SIMOTION D410‑2 is active. You can check this in NetPro. You will find a description of
how to reactivate the connection in Section Establishing a PG/PC assignment (Page 122).
6.6.2 Configuring the Ethernet connection in HW Config
The Ethernet connection of the SIMOTION D410‑2 can be configured in HW Config.
Procedure
1.
Open your project.
2. Open HW Config. Double-click the Ethernet port (X127 P1) to open the "Properties - PNxIE"
dialog box.
3. You can configure the Ethernet connection in the "Options" tab.
Recommendation: Use the default setting "Automatic setting". With Automatic setting, the
baud rate and duplex operating mode are automatically aligned with the connection partner.
The autocrossing functionality is also available so that you can use crossed and uncrossed
cables.
If transmission is to be set manually, not only must the connection (e.g. 10 Mbit/s half
duplex) be set manually but autonegotiation must also be deactivated.
Parameter assignment / addressing
6.6 Configuring an Ethernet subnet
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 135
