Siemens SIMOTION D410-2 DP User Manual

4.6 Connecting I/Os
Connecting cables
For the input/output wiring (X120, X121, X130, X131), use rigid or flexible cables with a
conductor cross-section as stated in the manual.
See
SIMOTION D410-2 Manual, Section "Digital inputs/outputs / temperature sensor / analog
input."
Note
To achieve optimum interference immunity, shielded cables must be used for connecting
analog signals, measuring inputs or external zero marks.
Tools required
Screwdriver 0.4 x 2.0 mm
Wiring inputs/outputs
1.
Strip 10 mm off the cable ends and press on a ferrule if required.
2. Wire:
– The digital inputs for connection of sensors.
– The digital outputs for the connection of actuators.
– The analog input
3. Insert the cable into the corresponding spring-loaded terminals of the interfaces. Pressure
can be applied to the spring with the tool to facilitate insertion.
Switching the analog input
For the use of the analog input (X131 connector) as analog voltage or current input, DIP switch
S5.0 must be switched accordingly:
Table 4-2 S5.0 switch positions
Position Function
U (left) The analog input is used as voltage input.
I (right) The analog input is used as current input.
Additional references
The connection examples for the wiring of the inputs/outputs can be found in the
SIMOTION D410-2 Manual, Section "Digital inputs/outputs / temperature sensor / analog
input".
Connecting
4.6 Connecting I/Os
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 59
