X127 (IE)
●
Active MAC Address: 08-00-06-73-25-3E
● IP address: 169.254.11.22
● Subnet mask: 255.255.0.0
● Standard gateway: 0.0.0.0.
As an alternative, you can determine the IP address as follows:
● By selecting "Project" > "Accessible nodes" in SIMOTION SCOUT
● By calling "Target system" > "Ethernet" > "Edit Ethernet node..." in HW Config and browsing
to "Online accessible nodes"
● Using the system function _getIpConfig
Note
The MAC address is listed on the nameplate on the front of the module.
Parameter assignment / addressing
6.6 Configuring an Ethernet subnet
SIMOTION D410-2
138 Commissioning and Hardware Installation Manual, 01/2015
