The following are not deleted:
●
CU operating hours counter
● CU temperature and
● Safety logbook
At the end of the deletion, the initialization data of the applications is in the NVRAM, similar to
after a device automatic commissioning (with the exception of the above-mentioned data).
Parameter p7775 is set to 0 at the end of the deletion.
Explanations for the parameter p7775
The following jobs can be set with the parameter p7775:
Value of the parameter p7775 Job
1 Backup NVRAM data (on CompactFlash card)
2 Restore NVRAM data (from CompactFlash card)
3 Delete NVRAM data on the Control Unit
The acknowledgement of a parameter job is delayed.
●
If the job cannot be executed, it is acknowledged negatively.
● If the job can be executed, it is acknowledged with the value 255.
Table 7-2 Acknowledgments of the parameter jobs
Acknowledge‐
ment
Description
17 Request cannot be executed because of the operating state
20 Illegal value
107 Write access is not permitted (cause: At least one DO has a pulse enable)
Because
the SINAMICS must perform a warm restart when restoring and deleting the
data, none of the connected drives may have a pulse enable.
132 Parameter change blocked (see p0300, p0400, p0922, p7760, macro being executed)
204 Write access not permitted
255 "OK": Job being executed
If an error is detected during the execution of a parameter job, the error cause is signaled via
the parameter itself (no message via the fault buffer).
Table 7-3
Causes of error for parameter jobs
Error Cause
10 Error occurred while deleting
11 No backup possible: Memory card is not inserted
12 No backup possible: Memory card is full
Commissioning (software)
7.4 Additional information on configuring the SINAMICS Integrated
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 179
