Table A-4 Local measuring inputs, configuration of the Measuring Input TO
Axis measuring sys‐
tem no.
Under axis measuring system number, enter the number of the used encoder
system (namely, encoder 1, 2 or 3). Encoder system 1 is the default setting.
Drive-related (local
measuring input)
Activate the checkbox when a local measuring input is used.
Measuring input num‐
ber
Enter here which measuring input is used (namely, 1 or 2). Input 1 is the
default setting.
Detailed information can be found in the
SIMOTION Motion Control Output Cams and
Measuring Inputs Function Manual.
Configuring drive-related I/Os (without symbolic assignment)
A.3 Configuring local measuring inputs
SIMOTION D410-2
Commissioning and Hardware Installation Manual, 01/2015 321
