r0747 CU digital outputs status
Display of the digital output status
Bit Signal name 0-signal 1-signal
08 DI/DO 8 (X122.7) Low High
09 DI/DO 9 (X122.8) Low High
10 DI/DO 10 (X122.10) Low High
11 DI/DO 11 (X122.11) Low High
12 DI/DO 12 (X132.7) Low High
13 DI/DO 13 (X132.8) Low High
14 DI/DO 14 (X132.10) Low High
15 DI/DO 15 (X132.11) Low High
Inversion via p0748 is taken into account.
It does matter whether DI/DO is set as an input or output (p0728).
DI/DO: Bidirectional digital input/output
r4022 TM31 digital inputs status
Display of the digital input status on the Terminal Module 31 (TM31)
Bit Signal name 0-signal 1-signal
00 DI 0 (X520.1) Low High
01 DI 1 (X520.2) Low High
02 DI 2 (X520.3) Low High
03 DI 3 (X520.4) Low High
04 DI 4 (X530.1) Low High
05 DI 5 (X530.2) Low High
06 DI 6 (X530.3) Low High
07 DI 7 (X530.4) Low High
08 DI/DO 8 (X541.2) Low High
09 DI/DO 9 (X541.3) Low High
10 DI/DO 10 (X541.4) Low High
11 DI/DO 11 (X541.5) Low High
DI: Digital input
DI/DO: Bidirectional digital input/output
r4047 TM31 digital outputs status
Display of the digital output status on the Terminal Module 31 (TM31)
Bit Signal name 0-signal 1-signal
00 DO 0 (X542.1 - 3) Low High
01 DO 1 (X542.4 - 6) Low High
08 DI/DO 8 (X541.2) Low High
09 DI/DO 9 (X541.3) Low High
10 DI/DO 10 (X541.4) Low High
