Communication via Ethernet/IP (EIP)
7.6 Supported objects
Communication
Function Manual, 12/2018, 6SL3097-5BD00-0BP0
197
No.
Service
Type
Name
Value/explanation
get_and_
clear
UINT32 Alignment Errors Structure received, which does not match the num-
ber of octets
UINT32 FCS Errors Structure received, which does not pass the FCS
check
UINT32 Single Collisions Structure successfully transmitted, precisely one
collision
UINT32 Multiple Colli-
sions
Structure successfully transmitted, several colli-
sions
UINT32
SQE Test Errors
Number of SQE errors
UINT32 Deferred Trans-
missions
First transmission attempt delayed
UINT32 Late Collisions Number of collisions that occurred delayed by 512
bit timers to the request
UINT32 Excessive Colli-
sions
Transmission unsuccessful as a result of intensive
collisions
UINT32 MAC Transmit
Errors
Transmission unsuccessful as a result of an internal
MAC sublayer transmission error.
UINT32 Carrier Sense
Errors
Number of errors when attempting to send a re-
quest frame, where the transmission condition was
lost or was not assigned
UINT32
Frame Too Long
Structure too large
UINT32 MAC Receive
Errors
Transmission unsuccessful as a result of an internal
MAC sublayer receive error.
6 get, set
Struct of
Interface Control
-
UINT16
Control Bits
-
UINT16 Forced Interface
Speed
-
10
get
String
Interface_Label
Interface-Label
11 get - Interface Capabil-
ity
Bit 0: Manual Setting
Bit 1: Auto-negotiate
Bit 2: Auto-MDIX
Bit 3: Manual Speed/Duplex
Bit 4 - 31: reserved
Remaining: Speed/Duplex Options
