4.2.4 Diagnostics options
The standard slave diagnostics can be read online in the HW config.
4.2.5 SIMATIC HMI addressing
You can use a SIMATIC HMI as a PROFIBUS master (master class 2) to access SINAMICS
directly. With respect to SIMATIC HMI, SINAMICS behaves like a SIMATIC S7. For
accessing drive parameters, the following applies:
● Parameter number = data block number
● Parameter sub-index = bit 0 ... 9 of data block offset
● Drive object number = bit 10 ... 15 of data block offset
Pro Tool and WinCC flexible
The SIMATIC HMI can be configured flexibly with "Pro Tool" or "WinCC flexible".
The following specific settings for drives must be observed when configuration is carried out
with Pro Tool or WinCC flexible.
Controllers: Protocol always "SIMATIC S7 - 300/400"
Table 4- 2 Additional parameters
Field
Value
Network parameter profile
DP
Network parameter baud rate Any
Communication partner address
PROFIBUS address of the drive unit
Communication partner
slot/rack
Don’t care, 0
Table 4- 3 Variables: "General" tab
Field
Value
Name
Any
Controller
Any
Type Depending on the addressed parameter value,
e.g.:
INT: for integer 16
DINT: for integer 32
WORD: for unsigned 16
REAL: for float
Area
DB
DB
(data block number)
Parameter number
1 ... 65535
