Diagnosis
Diagnostics using STARTER
6-210
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Properties
S Measuring functions
– Current controller setpoint change (downstream of the current setpoint filter)
– Current controller reference frequency response (downstream of the current
setpoint filter)
– Speed controller setpoint change (downstream of the speed setpoint filter)
– Speed controller disturbance step change (fault downstream of the current
setpoint filter)
– Speed controller reference frequency response (downstream of the speed
setpoint filter)
– Speed controller reference frequency response (upstream of the speed
setpoint filter)
– Speed controller interference frequency response (fault downstream of the
current setpoint filter)
– Speed controller path (excitation downstream of current setpoint filter)
Starting/stopping the measuring function
!
Caution
With the corresponding measuring function parameter settings (e.g. offset), the
motor can “drift” and travel to its end stop.
The movement of the drive is not monitored while the measuring function is active.
To start the ramp-function generator:
1. Meet the conditions for starting the measuring function
– Activate the control board
Drives -> Drive_x -> Commissioning -> Control board
– Switch on the drive
Control board -> Issue enable signals -> Switch on
2. Select the drive (as control board)
3. Set the measuring function
e.g. current controller setpoint change
4. Load the settings to the target system (“Download parameters” pushbutton)
5. Start the measuring function (“Start Measuring Function” pushbutton)
To stop the measuring function:
“Stop Measuring Function” pushbutton
