Diagnosis
Diagnostics using STARTER
6-211
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Parameterization
The “measuring function” parameter screen is selected via the following icon in the
toolbar of the STARTER commissioning tool:
Fig. 6-9 STARTER icon for “measuring function”
