Part programming
7.1 Part programming overview
Cylindrical grinding
102 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Use this softkey to select the program on which the cursor is placed for execution. If the CF
card is selected, the program is executed by the NC as an external program. This program
must not contain any program calls of part programs which are not stored in the directory of
the NC.
This softkey is needed in connection with the work in the network. Additional information is
provided in Chapter, network operation (only for SINUMERIK 802D sl pro).
The functions required for reading out/reading in files are provided via the RS232 interface.
Use this function to transmit files from the clipboard to a PC connected to the RS232.
Load files via the RS232 interface.
For the settings of the interface, please refer to the "System" operating area. The part
programs must be transmitted using the text format.
Error log
Selecting this softkey provides the functions required to read out / read in files via the
manufacturer drive and the function "Program execution from external". When the function is
selected, the directories of the manufacturer's drive are displayed.
Selecting this softkey provides the functions required to read out / read in files via USB
FlashDrive and the function "Program execution from external". When the function is
selected, the directories of the USB FlashDrive are displayed.
([W
H[HFXWLRQ
5&6
FRQQHFW
56
6HQG
5HFHLYH
(UURU
ORJ
0DQXIDF
WXUHUGULYH
86%
GULYH
