Programming
10.11 Subroutine technique
Cylindrical grinding
318 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
10.11.2 Calling machining cycles
Functionality
Cycles are technology subroutines that implement a certain machining process in a
universally valid way. Adaptation to the particular problem is performaed directly via supply
parameters/values when calling the respective cycle.
Programming example
N10 CYCLE83(110, 90, ...) ; Call of cycle 83, transfer values directly,
; separate block
…
N40 RTP=100 RFP= 95.5 ... ; Set transfer parameters for cycle 82
N50 CYCLE82(RTP, RFP, ...) ; Call of cycle 82, separate block
